Item number: 9212
TA S K C H A I R
Part #
Description
Quantity
1.
2.
3.
4.
5.
6A.
6B.
7.
8.
9.
10.
11.
12.
13.
Casters
5 Star Base
Telescoping Cover
Gas Lift
Seat Plate
Left Arm
Right Arm
Seat Cushion
Back Cushion
7/8” Big Screws
Back Support Plate (Already
attached to the back cushion)
1-1/8” Big Screws
1-3/4” Small Screws
Wrenches
5
1
1
1
1
1
1
1
1
4
1
4
8
2
A. Remove all parts from carton and separate them into part number groups as indicated in the parts list.
B. To begin assembly, place 5 star base (2) upside down and insert casters (1) into bottom of base (2).
C. Turn base (2) right side up on the floor and insert gas lift (4) into center hole on base (2).
D. Place telescoping cover (3) over the gas lift (4) and rest it on the base (2).
E. Tighten the arms (6A & 6B) onto the bottom of seat cushion (7) by using 1-3/4” small screws (12).
F. Attach seat plate (5) onto the bottom of seat cushion (7) (with front of seat plate facing front of seat
cushion) by using 7/8" big screws (9) and tighten screws.
G. Align back cushion (8) with seat cushion (7) by positioning back support plate (10) over the seat plate
(5) with 1-1/8" big screws (11) as shown in Diagram 1 and tighten screws.
H. Place the assembled chair on top of the gas lift (4) and press down until fully engaged.
I. Periodically (every 90 days) tighten all screws in the chair.
ATTENTION: Please ensure that all screws are fully tightened before using this chair.
A S S E M B L Y I N S T R U C T I O N S
P A R T S L I S T
