31
STEP 4—ATTACH METAL SHROUDS TO UPRIGHT ASSEMBLY
a. Using an allen wrench, socket wrench or open end wrench, and a fl at head screwdriver, remove and set aside the
shroud fasteners from the upright assembly using 4 hex screws, 4 lock nuts, 2 twist lock screws, and 2 lock washers.
1
45
67
