STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TR1F-2HS TFQY60E TFQX60S TFQX60P TFQX603
TR1F-2HS
DESIGN
• True’s solid door reach-in’s are designed with
enduring quality that protects your long term
investment.
• Designed using the highest quality materials
and components to provide the user with colder
product temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary tube
system using environmentally friendly (CFC free)
404A refrigerant.
• Extra large evaporator coil balanced with higher
horsepower compressor and large condenser
maintains -10°F (-23.3°C) cabinet temperature.
Ideal for both frozen foods and ice cream.
• Sealed, cast iron, self-lubricating evaporator fan
motor(s) and larger fan blades give True reach-
in’s a more effi cient low velocity, high volume
airfl ow design. This unique design insures faster
temperature recovery and shorter run times in the
busiest of foodservice environments.
• Top mounted refrigeration system with evaporator
positioned out of food zone to maximize capacity.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible defrost
cycle.
• Automatic evaporator fan motor delay during
defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors, front,
sides, back and bottom.
• Interior - 300 series stainless steel liner and fl oor.
• Insulation - entire cabinet structure and solid doors
are foamed-in-place using high density, CFC free,
polyurethane insulation.
• Welded, heavy duty galvanized frame rail dipped
in rust inhibiting enamel paint for corrosion
protection inside and out.
• Frame rail fi tted with 4" (102 mm) diameter stem
castors - locks provided on front set.
DOORS
• 300 series stainless steel exterior and liners. Doors
open within cabinet dimension.
• Door locks standard.
• Positive seal self-closing doors with 120° stay open
feature. Lifetime guaranteed door hinges.
• Lifetime guaranteed recessed door handles.
Each door fi tted with 12" (305 mm) long
recessed handles that are foamed-in-place with
a sheet metal interlock to ensure permanent
attachment.
• Magnetic door gaskets of one piece construction,
removable without tools for ease of cleaning.
SHELVING
• One (1) factory installed, interior kit option. Four
(4) different interior kits available (see Kit Options).
Pilasters and tray slides are factory installed at no
charge.
LIGHTING
• Incandescent interior lighting - light activated by
rocker switch mounted above top door, safety
shielded.
MODEL FEATURES
• Exterior digital temperature display, available with
either °F or °C display.
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• Backguard improves airfl ow.
• Minimum wattage heater in cabinet frame and
doors.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and ready
for fi nal connection to a 115/60/1 phase - 15 amp
dedicated outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/fl anged legs.
❒ 6" (153 mm) stainless steel legs.
❒ Stainless steel rail skirt for use with legs (fi eld
installed).
❒ Metal door handles (factory installed).
❒ Electronic temperature control (factory installed).
❒ Curb mountable units.
❒ Remote cabinets (condensing unit supplied
by others; system comes standard with 404A
expansion valve and requires R404A refrigerant).
Consult factory technical service department for
BTU information.
KIT OPTIONS
❒ Kit #1: Nine (9) sets of #1 type tray slides and
pilasters (factory installed), bottom support of one
(1) 18"L x 26"D (458 mm x 661 mm) pan or two (2)
14"L x 18"D (356 mm x 458 mm) pans.
❒ Kit #2: One (1) set half-section #2 steel rod tray
slides and pilasters (factory installed), rim support
of one (1) 18"L x 26"D (458 mm x 661 mm) pan.
❒ Kit #3: Six (6) sets of universal type tray slides and
pilasters (factory installed), bottom support of one
(1) 18"L x 26"D (458 mm x 661 mm) pan, two (2)
14"L x 18"D (356 mm x 458 mm) pans or two (2)
12"L x 20"D (305 mm x 508 mm) pans
❒ Kit #4: Three (3) chrome shelves
25"L x 27
3
/
4
"D
(635 mm x 705 mm
). Four (4) shelf supports
included per shelf (factory installed). Shelves
adjustable on 6” (153 mm) increments.
❒ Additional kit option components available
individually.
TR Series:
Reach-In Solid Half Door Freezer
115/60/1
NEMA-5-15R
ELEVATION
78
3
/16"
(1986 mm)
84
3
/16"
(2139 mm)
5"
(127 mm)
1"
(26 mm)
PLAN VIEW
1
3
/16"
(31 mm)
29"
(737 mm)
34
5
/8"
(880 mm)
26
23
/32"
(679 mm)
61
11
/32"
(1559 mm)
77"
(1956 mm)
38
5
/8"
(982 mm)
4"
(102 mm)
