TRYBIKE DISCOVER THE WORLD
WHAT IS IN THE BOX?
• Bag with long rear axle, three aluminium pipes, four short black nylon bushings and two
long nuts of which one nut is sealed to the axle.
• Allen keys
• 1 wheel
TRYBIKE THE GROWBIKE
ASSEMBLY OF THE LONG REAR AXLE AND THE TWO REAR WHEELS
Remove the parts of the long axle, please note: one nut is sealed and only one nut can be
unscrewed. Insert the short aluminium pipe in between the rear forks. Insert the short black
bushings into the wheels, with the narrow part of the bushings into the wheel bearings. Then
slide one wheel with the bushings over the rear axle up to the sealed nut at the end of the axle.
Push the long aluminium pipe over the axle up to the wheel and slide the axle, from the le
side of the rider, into the holes of the rear forks and through the aluminium pipe. Important,
keep the sealed nut on the le side of the rider. This way the nut on the other side won’t turn
loose when the Trybike is ridden. Slide the remaining long aluminium pipe and the wheel with
the bushings onto the right side of the rear axle and fasten the wheel with the nut. Finally,
ghten the nut properly (not too ght but also not too loose) and check that the wheels rotate
smoothly and the nuts don’t turn. Put the short axle in the supplied bag and store it, so you can
convert the tricycle to a bicycle in the future.
LE
ARNING
TO
WA
LK & RIDE
