- 17 -
4. Place the paper, printing side face up,
through the media sensor and place
the label leading edge onto the platen
roller.
5. Move the media guides to fit the label
width by pushing the media guide
adjustment button.
6. Close the top cover gently.
7. Use “Diagnostic Tool” to set the media
sensor type and calibrate the selected
sensor. (Start the “Diagnostic tool” 
Select the “Printer Configuration” tab 
Click the “Calibrate Sensor” button )
Please refer to the diagnostic utility
quick start guide for more information.
Note:
Please calibrate the gap/black mark
sensor when changing media.
PUSH
