Drive Connectors: TSST SH-216CB DVD+/-RW
Drive User's Guide
SATA Drive Connector
SATA Drive Connector
There are two connectors at the back of the drive unit.
1. Serial ATA Interface Connector (ATA)
7-pin Serial ATA male connector.
2. Power Connector
The drive has a DC power connector assembly, which consists of a 15-pin shrouded, keyed,
male power connector as shown above.
