TTI TG550 - PCB Assy Main Components (Page 19)

Part No. Description Position
23202-3130 RES 13K0F W25 MF 50PPM R145,223
23202-3150 RES 15K0F W25 MF 50PPM R57,105,109,113
23202-3220 RES 22K0F W25 MF 50PPM R97,165,184,235
23202-3226 RES 22K6F W25 MF 50PPM R104
23202-3249 RES 24K9F W25 MF 50PPM R111
23202-3270 RES 27K0F W25 MF 50PPM R22
23202-3300 RES 30K0F W25 MF 50PPM R16,69,154,234
23202-3330 RES 33K0F W25 MF 50PPM R15,185
23202-3360 RES 36K0F W25 MF 50PPM R3,228
23202-3390 RES 39K0F W25 MF 50PPM R7,9
23202-3430 RES 43K0F W25 MF 50PPM R143
23202-3470 RES 47K0F W25 MF 50PPM R55,141
23202-3510 RES 51K0F W25 MF 50PPM R6
23202-3560 RES 56K0F W25 MF 50PPM R117,169
23202-4100 RES 100KF W25 MF 50PPM R27,28,64,94,166,188,230
23202-4110 RES 110KF W25 MF 50PPM R225
23202-4180 RES 180KF W25 MF 50PPM R56
23202-4270 RES 270KF W25 MF 50PPM R80,224
23202-5100 RES 1M00F W25 MF 50PPM R95,189
23202-5470 RES 4M70F W25 MF 50PPM R20
23202-6100 RES 10M0F W25 MF 50PPM R5,174
23206-0102 RES 10R2F W60 MF 50PPM R134
23206-0412 RES 41R2F W60 MF 50PPM R132,133
23206-0510 RES 51R0F W60 MF 50PPM R135,137
23206-1600 RES 600RF W60 MF 50PPM R73
23215-3100 RES 10K0B W25 MF 15PPM R236,237
23222-0100 RES 10R0J W33 MF FUSIBLE NFR25 R9
23377-1100 RES PS/H 100R CF 10MM VR8
23377-1470 RES PS/H 470R CF 10MM VR14,20,23,24
23377-2100 RES PS/H 1K0 CF 10MM VR12,38
23377-2220 RES PS/H 2K2 CF 10MM VR21
23377-3100 RES PS/H 10K CF 10MM VR3,6,7,9,13,18,22,37
23377-3220 RES PS/H 22K CF 10MM VR2,4,5,11,19,36
23377-3470 RES PS/H 47K CF 10MM VR15,16,17
23379-1100 RES PS/H 100R CERMET 10mm skel VR10
23387-1680 RES 680RJ .25S TEMPERATURE DEP TDR1
PCB ASSY MAIN (44912-0450) continued/…
19
