No. of outputs: 1
OUTPUT VOLTAGE: 56V
WAVE SHAPE: SINUSOIDAL
WIDTH OF IMPULSES: 140 μSec.
NO. OF PROGRAMS: 1
OUTPUT CURRENT : 56 mA (load 1kohm)MAX
CARRIER FREQUENCY: 7.500 Hz
MODULATION FREQUENCY : 70 Hz
SUPPLY VOLTAGE: 8.4 V (Rechargeable battery)
9 V (Alcaline battery)
CONTRACTION TIME: 3 Sec.
RECOVERY TIME: 3 Sec.
WEIGHT: 222 g (with battery)
DIMENSIONS: 184 x 55 x 445
OPERATING CONDITIONS: Temperature: from 0 to 35°C
Humidity: from 20 to 65% RH
STORAGE: Temperature: from 5 to 40 °C
Humidity: from 10 to 85% RH
MARKING:
TECHNICAL DETAILS
