MSL-IV PARTS LIST
e
m N
o
Description Part No. Qty
t
em N
o
Description Part No. Qt
y
1 PRESS BAR MSL4-01-00 1 59 COIL CHAIN 3/16 X 21 BNH0017 1
2 BASE FRAME MSL4-02-00 1 60 HARD GRIP .875 X 8 BNH0523 6
3 FRONT UPRIGHT MSL4-03-00 1 61 SET SCREW 3/8-16 X 1/2 BNH0474 2
4 REAR UPRIGHT MSL4-04-00 1 62 RUBBER STOPPER 1 X 2 X 2 3/4 BNH0611 1
5 TOP PULLEY ASSEMBLY MSL4-05-00 1 63 PLASTIC END CAP 2" SQ W/GROOVE BNH0050 4
6 NYLON WASHER 3/8 USS BNH0248 4 64 PLASTIC INSERT CAP 2" SQ BNH0012 1
2
7 PEC DEC ARM MSL4-07-00 2 65 PLASTIC INSERT CAP 1" RD BNH0002 6
8 HEX HEAD CAP SCREW 3/8-16 X 3 1/2 BNH0280
1 66 PLASTIC INSERT CAP 1 1/2 SQ BNH0009 1
9 PEC DEC CAM MSL4-08-00 2 67 PLASTIC INSERT CAP 1 X 2 BNH0005 7
10 BACK PAD ADJUSTMENT BRACKET UP179 1 68 PLASTIC INSERT CAP 1 1/4 RD BNH0573 4
11 PEC DEC HANDLE BRACKET (LEFT) MSL4-11-00 1 69 HEX KEY LONG 1/8" BNH0767 1
12 PEC DEC HOUSING MSL4-12-00 1 70 RUBBER HOSE 1 1/4 X 5 1/2 BNH0807 2
13 PEC DEC ARM/ CAM SUPPORT MSL4-13-00 2 71 RUBBER HOSE 1 1/4 X 7 BNH0807 4
14 LAT CABLE MSL4-14-00 1 72 NYLON SPACER 3/8 X 3/8 BNH0392 5
15 LEG EXTENSION CABLE MSL4-15-00 1 73 NYLON BUSHING 1 X 1 1/2 BNH0531 4
16 PEC DEC CABLE MSL4-16-00 1 74 BRONZE BUSHING 1 X 1 1/4 BNH0527 1
0
17 LOW ROW CABLE MSL4-17-00 1 75 HEX HEAD CAP SCREW 3/8-16 X 3 3/4 BNH0281 1
18 NYLON STEM BUTTON 5/16 BNH0533 2 76 HEX HEAD CAP SCREW 3/8-16 X 3 1/4 BNH0312 3
19 PIVOT AXLE 1 X 11 3/4 UP067 1 77 HEX HEAD CAP SCREW 3/8-16 X 2 3/4 BNH0278 11
20 GUIDE ROD 1 X 72 UP124 2 78 HEX HEAD CAP SCREW 3/8-016 X 2 1/2 BNH0276 4
21 DOUBLE PULLEY PLATE 1/8 X 2 X 9 UP092 2 79 HEX HEAD CAP SCREW 3/8-16 X 1 3/4 BNH0274 1
6
22 LAT BAR HOLDER 2 X 3 UP096 1 80 SHOULDER BOLT 3/8 X 3/4 BNH0718 2
23 OFFSET PULLEY BRACKET UP121 2 81 HEX HEAD CAP SCREW 3/8-16 X 1 BNH0275 6
24 PEC DEC SEAT PAD UP122 1 82 SPLIT WASHER 1/2" BNH0572 1
25 PEC DEC SWIVAL PULLEY BRACKET UP126 3 83 STRAP BRACKET #20 BNH0562 2
26 ADJ PULLEY BRACKET UP127 1 84 NYLON INSERT LOCK NUT 5/16-18 BNH0215 2
27 PEC DEC SEAT ADJ TUBE UP133 1 85 NYLON BALL 1 3/4 X 5/16 BNH0392 3
28 LAT BAR CHROME 48" UP093 1 86 NYLON INSERT JAM LOCK NUT 3/8-16 BNH0365 2
8
29 LOW ROW BAR 16" UP094 1 87 NYLON INSERT LOCK NUT 3/8-16 BNH0214 9
30 WEIGHT SELECTOR PIN BNH0064 1 88 NYLON INSERT JAM LOCK NUT 1/2-13 BNH0366 9
31 PLASTIC TUBE GUIDE 2 1/2 SQ BNH0060 2 89 FLAT WASHER SAE 1/2" BNH0238 7
32 FOAM FOOT ROLL 7 X 4 X 1 BNH0043 6 90 FLAT WASHER SAE 3/8" BNH0239 8
4
33 RUBBER BUMPER 3/8 X 1 1/2 BNH0514 1 91 BUMPER CAP BLACK BNH0412 2
34 BLACK CASTER 2 X 1 BNH0633 1 92 HEX HEAD CAP SCREW 1/2-13 X 2 3/4 BNH0261 1
35 NYLON PULLEY 4 1/2 RD BNH0556 19 93 HEX HEAD CAP SCREW 3/8-16 X 4 1/2 BNH0284 1
36 SNAP LINK ZINC BNH0065 3 94 HEX HEAD CAP SCREW 3/8-16 X 3 BNH0282 4
37 LOW ROW FOOT SUPPORT UP177 1 95 SHOULDER BOLT 3/8 X 3/8 BNH0422 1
38 LEG EXTENSION BENCH FRAME UP172 1 96 HEX HEAD CAP SCREW 1/2-13 X 3 1/4 BNH0576 1
39 BENCH PRESS ADJ SEAT TUBE UP171 1 97 HANDLE BRACKET (RIGHT) MSL4-97-00 1
40 PUSH-PULL PIN 1/2" (SPECIAL) BNH0516 3 98 HEX HEAD CAP SCREW 1/2-13 X 3 BNH0264 2
41 RUBBER DONUT BNH0062 2 99 HEX HEAD CAP SCREW 3/8-16 X 4 1/4 BNH0317 3
42 LEG EXTENSION ARM UP150 1 100 FOOT ROLL TUBE 1 X 16 UP053 2
43 PEC DEC BACK PAD UP147 1 101 PLASTIC INSERT CAP 2 X 3 BNH0052 1
44 BACK PAD (BENCH PRESS) MSL4-44-00 1 102 SOCKET HEAD CAP SCREW 1/4 X 3/4 BNH0452 2
45 SEAT PAD (BENCH PRESS) UP173 1 103 NYLON INSERT LOCK NUT 1/4-20 BNH0213 2
46 FOOT ROLL BRACKET UP176 1 104 HEX HEAD CAP SCREW 3/8-16 X 1 1/4 BNH0273 4
47 RANGE OF MOTION TUBE MSL4-47-00 1 105 SET SCREW 1/4-20 X 1/4 BNH0790 2
48 RANGE OF MOTION DEVICE MSL4-48-00 1 106 FENDER WASHER 3/8 X 1 1/2 BNH0195 6
49 RETAINING SNAP RING BNH0419 2 107 CABLE RETAINER BRACKET LARGE UP160 1
50 HEX KEY 3/16 BNH0371 1 108 BUMPER WASHER 3/8 BNH0498 2
51 SPLIT BOLT 1/2-13 X 1 BNH0479 1 109 PVC TUBE 1 X 7 BNH0417 2
52 10 LB WEIGHT PLATE GREY BNH0561 19 110 NYLON SPACER 3/8 X 7/8 X 3/4 BNH0726 1
53 ABDOMINAL STRAP BNH0821 1 111 CABLE RETAINER BRACKET UP014 2
54 GUIDE ROD RETAINER HOUSING UP169 1 112 VELCRO ANKLE STRAP 20000-VNAS 1
55 FOOT ROLL TUBE 1 X 23 3/4 UP180 1 113 AXLE TUBE 1 X 7 MSL4-113-00 2
56 PUSH-PULL PIN 1/2" BNH0515 3 114 TUBEING CONNECTOR 3/8-16 BNH0551 4
57 AB CRUNCH INSERT BRACKET UP119 1 115 BRONZE BUSHING 1/2 X 5/8 BNH0528 2
58 TOP PLATE/ SELECTOR BAR UP003 1 116 STAINLESS STEEL TAPE 1 X 8 BNH0740 1
COLOR
CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
M
SL-IV Muscle IV Home Gym
20
