9
A. Attach the Bench Frame (#9) to the Base Frame (#1) using one Hex Head Cap Screw 3/8-16 X 4 1/2 (#57),
two Flat Washers SAE 3/8” (#44), and one Nylon Insert Jam Lock Nut 3/8-16 (#69).
B. Attach the Bench Frame (#9) to the Front Frame (#2) using one Hex Head Cap Screw 3/8-16 X 2 3/4 (#54),
two Flat Washers SAE 3/8” (#44), and one Nylon Insert Jam Lock Nut 3/8-16 (#69).
ACS-100 Free Movement Adjustable Cable System
Step 5 Assembling the Bench Frame to the Base Frame and Front Frame
Assembly List
Item # Description Qty.
9 LEG EXTENSION BENCH FRAME 1
42 FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4 1
44 FLAT WASHER SAE B/O 3/8” 4
54 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 3/4 1
57 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/2 1
69 NYLON INSERT JAM LOCK NUT B/O 3/8-16 2
96 TURN/PULL PIN W/KNOB AND LOCK 1
