11
A. Using a rubber mallet, insert two Plastic Insert Caps 1 3/4 Sq. (#74) into the tube-ends of the Leg Extension
Arm (#11).
B. Attach the Leg Extension Arm (#11) to the Bench Frame (#9) using the Sex Bolt Female 1/2 X 2 5/16 (#86)
and the Sex Bolt Male 5/16-20 X 3/4 (#87).
C. Attach a Nylon Pulley 3 1/2 Rd. (#71) to the Leg Extension Arm (#11) using hardware shown.
ACS-100 Free Movement Adjustable Cable System
Step 6 Assembling the Leg Extension Arm to the Bench Frame
Assembly List
Item # Description Qty.
11 LEG EXTENSION ARM 1
38 BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8 4
44 FLAT WASHER SAE B/O 3/8” 2
53 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/4 1
60 L-LOCKING PIN 1
69 NYLON INSERT JAM LOCK NUT B/O 3/8-16 1
71 NYLON PULLEY 3 1/2 RD, WHITE 1
74 PLASTIC INSERT CAP 1 3/4” SQ. 10-14 GA. 2
86 SEX BOLT FEMALE 1/2 X 2 5/16 1
87 SEX BOLT MALE 5/16-20 X 3/4 1
97 URETHANE BUMPER 1 3/4 1
