27
A. Attach the Tension Cable (#31) to the Floating Pulley Bracket (#22) and secure it into place using one
shoulder Bolt 3/8 X 3/4 (#88) and one Nylon Insert Lock Nut 5/16-18 (#67).
B. Route the Cable down and secure it to the Bottom Support Pulley Brkt (#18) using one Hex Head Cap Screw
3/8-16 X 1 3/4 (#50), two Flat Washers SAE 3/8” (#44), two Nylon Spacers 3/8 X 3/4 X 3/8 (#72), and one Nylon
Insert Jam Lock Nut 3/8-16 (#69).
ACS-100 Free Movement Adjustable Cable System
Step 13 Routing of the Tension Cable
Assembly List
Item # Description Qty.
31 TENSION CABLE 1
44 FLAT WASHER SAE B/O 3/8” 2
50 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 1
67 NYLON INSERT LOCK NUT B/O 5/16-18 1
69 NYLON INSERT JAM LOCK NUT B/O 3/8-16 1
72 NYLON SPACER 3/8 X 3/4 X 3/8 2
88 SHOULDER BOLT ALLOY 3/8 X 3/4 1
To Next Page
