ACS-100 Free Movement Adjustable Cable System
Step 17 Seat Pad & Foot Roll Bracket Assembly
Assembly List
Item # Description Qty.
10 ADJUSTABLE SEAT FRAME 1
12 FOOT ROLL TUBE 1 X 18 1
13 FOOT ROLL BRACKET 1
26 SEAT PAD 1
32 FOAM ROLL 1 X 4 X 7 1/4 4
43 FLAT WASHER SAE B/O 1/2” 2
44 FLAT WASHER SAE B/O 3/8” 2
46 FOOT ROLL PLASTIC END CAP 1” 4
47 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 3 1/2 1
50 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 2
68 NYLON INSERT JAM LOCK NUT B/O 1/2-13 1
75 PLASTIC INSERT CAP 1” X 2”_ 10-14 GA. 1
90 SOCKET SET SCREW ALLOY 1/4-20 X 1/4 1
A. Using a rubber mallet, insert one Plastic Insert Cap 1 X 2 (#75) into the tube-end of the Adjustable Seat Frame
(#10).
B. Attach the Seat Pad (#26) to the Adjustable Seat Frame (#10) using two Hex Head Cap Screws
3/8-16 X 1 3/4 (#50), and two Flat Washers SAE 3/8” (#44).
C. Insert the Foot Roll Tube 1 X 18 (#12) into the receptacle of the Adjustable Seat Frame (#10). Use a
measuring tape to center the Foot Roll Tube 1 X 18 (#12) to the Adjustable Seat Frame (#10) and secure it
into place using one Socket Set Screw 1/4-20 X 1/4 (#90).
D. Attach the Foot Roll Bracket (#13) to the Leg Extension Arm (#11) using one Hex Head Cap Screw
1/2-13 X 3 1/2 (#47), two Flat Washers SAE 1/2” (#43), and one Nylon Insert Jam Lock Nut 1/2-13 (#68).
E. Attach Foam Rolls 1 X 4 X 7 1/4 (#32) and Foot Roll Plastic End Caps 1” (#46) to the Foot Roll Tube 1 X 18
(#12) and the Foot Roll Bracket (#13).
