ACS-100 Free Movement Adjustable Cable System
Item No.
Description Part No. Qty
Item No.
Description Part No. Qty
1 BASE FRAME UP2810 1 56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 BNH0312 5
2 FRONT FRAME UP2813 1 57 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/2 BNH0284 1
3 BACK PAD ADJUSTABLE BRACKET UP0554 1 58 HEX KEY 1/8" BNH0767 1
4 FOOT ROLL TUBE 1 X 27 UP0743 1 59 HEX KEY 3/16" BNH0371 1
5 REAR FRAME UP2814 1 60 L-LOCKING PIN BNH0045 1
6 SELECTORIZED UPRIGHT RT UP2811 1 61 LOW ROW BAR 20" BNH0294 1
7 SELECTORIZED UPRIGHT LT UP2812 1 62 METAL HINGE BNH0046 2
8 CHROME SOLID GUIDE ROD 3/4 X 72 UP0124 2 63 NYLON BALL 1 3/4 X 5/16 BNH0047 3
9 LEG EXTENSION BENCH FRAME UP2809 1 64 NYLON D HANDLE (# H834A) BNH1215 2
10 ADJUSTABLE SEAT FRAME UP2806 1 65 NYLON FLAT WASHER 3/8 BNH0248 2
11 LEG EXTENSION ARM UP2804 1 66 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 6
12 FOOT ROLL TUBE 1 X 18 UP2808 1 67 NYLON INSERT LOCK NUT B/O 5/16-18 BNH0215 5
13 FOOT ROLL BRACKET UP2815 1 68 NYLON INSERT JAM NUT B/O 1/2-13 BNH0366 1
14 GUIDE ROD RETAINER UP2807 1 69 NYLON INSERT JAM LOCK NUT B/O 3/8-16 BNH0365 41
15 CARRIAGE UP2797 2 70 NYLON PULLEY 4 1/2 RD., WHITE BNH0556 2
16 HIGH/LOW DOUBLE PULLEY BRKT UP1023 2 71 NYLON PULLEY 3 1/2 RD., WHITE BNH1136 31
17 TOP SUPPORT PULLEY BRACKET UP2799 1 72 NYLON SPACER 3/8 X 3/4 X 3/8 BNH0392 2
18 BOTTOM SUPPORT PULLEY BRKT UP2805 1 73 PLASTIC END CAP W/GROOVE 3 X 2 GREY BNH0134 3
19 WEIGHT SHIELD, REAR UP2816 1 74 PLASTIC INSERT CAP 1 3/4" SQ. 10-14 GA. BNH0053 2
20 WEIGHT SHIELD, FRONT UP2817 1 75 PLASTIC INSERT CAP 1" X 2"_ 10-14 GA. BNH0005 3
21 ADJUSTABLE STOPPER UP2800 2 76 PLASTIC INSERT CAP 2" SQ BNH0012 1
22 FLOATING PULLEY BRACKET UP2801 1 77 PLASTIC TUBE END 1 X 1 1/4 X 3/8 BNH1089 2
23 TOP PLATE PULLEY BRACKET UP2802 1 78 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/2" SQ. BNH0060 4
24 CLOSED END ADJUSTABLE PULLEY BKT UP2803 2 79 PUSH PULL PIN 1/2 X 2 7/8 LIGHT SPRING BNH0542 2
25 CABLE RETAINER BRACKET UP0998 8 80 PUSH PULL PIN 1/2 X 3 1/2 REGULAR BNH0520 1
26 SEAT PAD UP0173 1 81 RETAINING SNAP RING EXT. PLAIN .925 X 1 X .042 BNH0419 2
27 BACK PAD UP0370 1 82 RUBBER BUMPER 3/8 X 1 1/2 BNH0514 1
28 SELECTOR PIN W/COIL 3/8 X 3 1/2 GOLD KNOB UP3051 1 83 RUBBER DONUT 3/4 X 2 1/2 BNH0068 2
29 CROSSOVER CABLE UP2819 2 84 RUBBER GRIP 1 X 6 1/4 BNH0296 2
30 LEG EXTENSION / ABDOMINAL CABLE UP2820 1 85 RUBBER GROMMET 3/4" ID (2867-012) BNH0401 2
31 TENSION CABLE UP2818 1 86 SEX BOLT FEMALE 1/2 X 2 5/16 BNH1393 1
32 FOAM ROLL 1 X 4 X 7 1/4 UP0375
6 87 SEX BOLT MALE 5/16-20 X 3/4 BNH1392 1
33 10 LB CAST WEIGHT PLATE GREY BNH0904 19 88 SHOULDER BOLT ALLOY 3/8 X 3/4 BNH0718 5
34 10 LB TOP PLATE/SELECTOR BAR GREY 19 WTS. BNH0932 1 89 SNAP LINK Z/P 8MM X 80MM BNH0065 3
35 ABDOMINAL CRUNCH HARNESS BNH0235 1 90 SOCKET SET SCREW ALLOY 1/4-20 X 1/4 BNH0790 2
36 ANKLE STRAP BNH1435 1 91 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 BNH1131 2
37 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 4 92 SPLIT LOCK WASHER B/O 1/2" BNH0653 7
38 BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8 BNH0528 4 93 SPLIT LOCK WASHER B/O 3/8" BNH0658 2
39 BRONZE BUSHING 3/8 X 1/2 X 1/2 X 11/16 X 1/16 BNH0738 2 94 HEX KEY M8 BNH0571 1
40 EDGE PROTECTOR BLACK 1/16 BNH0587 4 95 STRAP BRACKET 20 #SF20 STAINLESS STEEL BNH0562 4
41 FINISHED HEX NUT B/O 1/2-13 BNH0201 7 96 TURN/PULL PIN W/KNOB AND LOCK BNH0989 1
42 FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4 BNH0408 1 97 URETHANE BUMPER 1 3/4 BNH0229 1
43 FLAT WASHER SAE B/O 1/2" BNH0238 2 98 U-STYLE TAPPED HOLE NUT 1/4-20 BNH0708 8
44 FLAT WASHER SAE B/O 3/8" BNH0239 100 99 COIL CHAIN Z/P 3/16 X 21 BNH1262 1
45 FLAT WASHER USS B/O 1/4" BNH0233 8 100 DECAL-EXERCISE CHART BNH1486 2
46 FOOT ROLL PLASTIC END CAP 1" BNH0397 6 101 DECAL-NUMBERS 1-28 BNH1487 2
47 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 3 1/2 BNH0263 1 102 DECAL-ADJUST CABLE HERE BNH0789 4
48 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4 BNH0890 8 103 DECAL-CAUTION 1 3/4 X 5 1/2 BNH0126 1
49 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4 BNH0273 3 104 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH0142 3
50 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 27 105 DECAL-FOR BEST PERFORMANCE 1 1/4 X 1 1/2 BNH0143 1
51 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 BNH0279 5 106 DECAL-LARGE TUFFSTUFF BNH0360 1
52 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/2 BNH0276 3 107 DECAL-NUMBERS 20-200 LBS. SET BNH0902 1
53 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/4 BNH0277 1 108 DECAL-WARNING KEEP HANDS AND FINGERS.. BNH0620 2
54 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 3/4 BNH0278 7 109 NYLON BALL W/THREADED SOCKET 1 3/4 X 5/16 BNH0022 1
55 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 BNH0282 2 110 SOCKET SET SCREW ALLOY 3/8-16 X 3/4 BNH0476 1
ACS-100
Parts List
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
To Next Page
