5
A. Install the two Adjustable Stoppers (#21) to the Rear Frame (#5) using hardware shown.
B. Assemble the two Closed End Adjustable Pulley Brkts (#24) and the Floating Pulley Bracket (#22) using
hardware shown
ACS-100 Free Movement Adjustable Cable System
Step 3 Assembly of the Adjustable Stoppers and the Floating Pulley Brackets
Assembly List
Item # Description Qty.
21 ADJUSTABLE STOPPER 2
22 FLOATING PULLEY BRACKET 1
24 CLOSED END ADJUSTABLE PULLEY BRKT 2
41 FINISHED HEX NUT B/O 1/2-13 4
44 FLAT WASHER SAE B/O 3/8” 10
50 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 5
69 NYLON INSERT JAM LOCK NUT B/O 3/8-16 5
71 NYLON PULLEY 3 1/2 RD, WHITE 5
92 SPLIT LOCK WASHER B/O 1/2” 4
