1-2-7
Orig
CD389
Chapter 1
GT110 (24V0 Aircraft Tow Tractor Section 2
Table 2-2. Front Cab Instrument Panel
ITEM NAME DESCRIPTION
1
Emergency Engine Stop Button This shuts down the engine in an emergency situation.
Press down on the button to stop the engine. To reset,
pull up on the button.
2
Left Turn Indicator This light illuminates when the left turn signal is on.
3
Low Oil Pressure Light This light illuminates whenever the engine oil pressure
drops below 5.8 psi (39.99 kPa).
4
Engine Fault Light This light illuminates whenever the engine experiences
a fault condition
5
Glow Plug Light This light illuminates whenever the glow plugs come on
and goes out when they reach the proper temperature.
The engine is then ready to start.
6
Alternator No Charge Light This light illuminates when the alternator is not
charging the electrical system.
7
Dash Panel Lights
The dash panel lights are used to illuminate the
instrument panel during low-light conditions. These
lights automatically turn on when the Parking/Headlight
Switch is turned on.
8
Multifunction LCD Display Panel The multifunction LCD display shows vehicle and
engine data gauges including: tachometer, vehicle
speed, fuel level, coolant temperature, oil pressure and
transmission oil temperature. The display will also
show the user if any engine or transmission fault codes
are present as well as give a description of the
fault.When the tractor is in reverse, the display will
change to show the rear view camera.
9
Transmission Warning Light This light illuminates when a problem occurs with the
transmission.
10 Four-Wheel Steering System
Warning Light
This light illuminates when a problem occurs with the
four-wheel steering system.
11 High Beam Indicator This light tells the operator that high beam headlights
are selected.
