Tuthill KINNEY KD Series Manual

Manual 1808 Rev B p/n 001808 0000
29
10
Replacement Parts
KD-50B PARTS LIST
ITEM
NO.
DESCRIPTION QTY
1 Cylinder 1
2 Head, Open & Closed End 2
3
Housing, Shaft Seal &
Bearing
1
4 Cap, Closed End 1
5 Cover, Cylinder 1
6** Gasket, Cylinder Cover 1
7 Cam, Open End (Heavy) 1
8 Cam, Closed End 1
9 Piston 2
10 Slidepin 2
11 Shaft 1
12** Discharge Valve 2
13 Plate, Valve Hold Down 2
14 Bearing, Head 2
15
Spacer, Bearing, Open
Head
1
16 Bearing Assmbly, Out. 1
16A Ball Bearing w/ ID Taper 1
16B Bearing Adapter 1
17** Shaft Seal, 3/4 Viton 1
18** Retaining Ring, .75 Ext. 1
19** O-Ring, 2-27 Buna-N 2
20 Key, Cam, Woodruff 13 2
21
Key, Drive, 3/16 sq. x
1-1/4 lg.
1
22 Dowel Pin 1/8 dia. x 1/2 lg. 1
23 Dowel Pin 5/16 dia. x 7/8 lg. 4
24
Hex Head Cap Screw,
5/16-18 x 3/4 lg.
36
25
Hex Head Cap Screw,
5/16-18 x 7/8 lg.
10
26
Socket Head Cap Screw,
5/16-18 x 7/8 lg.
1
27
Socket Head Cap Screw,
5/16-18 x 5/8 lg.
6
28
Pipe Plug, Hex Sock,
1/8 NPT
2
ITEM
NO.
DESCRIPTION QTY
29 Gas Ballast Valve 1
30 Drain Cock, Oil, 1/4 NPT 1
31
Discharge Separator Tank
Assy.
1
31A** Flange Gasket 1
31B Oil Mist Eliminator Element 1
31D** Check Disc, Viton 1
31E Dispersion Screen 1
31F Sightglass, 2" NPT 1
31G Oil Drain Cock, 1/2 NPT 1
31H* Seal Nut, 1-1/2 NPT 1
31I* Reinforcing Plate 1
32* Solenoid Valve 240/480V 1
33* Pump Sheave 1
34*
V-Belt 3VX375 (w/ FR 56
motor)
1
34*
V-Belt 3VX470 (w/ FR145T
motor)
1
* Item Not Shown. Item 31, Bolting Hardware, not
shown.
** Item included in repair/maintenance kit
