DVI/PC to HD/SD Converters
Models C2-2105A, 2155A
www.tvone.com • www.tvone.eu
www.tvonela.com
www.tvoneasia.com
Specifications
Computer Inputs
Signal Type
1x Analog via HD-15F w/Loop-thru
1x DVI-D via DVI-I Connector
Format RGBHV, RGBS, RGsB, YPbPr
Sync
TTL Level, 10KΩ, Pos or Neg
Termination
75Ω
R-G-B Level Range 0.5-2.0 Vp-p
Scan Rate Detection Automatic
Analog Signals PC to 2048x2048,HD to 1080p/60
DVI Signals PC to 1920x1024,HD to 1080p/60
Vertical Refresh Rate Any to 250Hz
Max Horiz Scan Rate 150KHz
Computer Compatibility PC, Macintosh, Workstations
Video Outputs
Television Standards
NTSC, PAL, PAL-M, PAL-N, SECAM
Impedance
75Ω
RGB/YPbPr Loop-thru 1x Active Buffered via HD-15
Composite Video 1x via BNC
YC (S-Video) 1x via 4-PIN Mini-DIN
YUV, YPbPr 1x via 3-BNC
SD/HD-SDI 1x via BNC
Video Inputs
(Note 1)
Composite Video 1x via BNC (C2-2155A)
YC (S-Video) 1x via 4-Pin Mini-DIN (C2-2155A)
Genlock (Composite) 1x via BNC (C2-2105A)
General
Size and Position Automatic via AutoSet or Manual
Image Size User-Definable Presets
Image Freeze One Video Frame
Settings Memory Non-Volatile
Zoom Range Variable to 10X Zoom
Shrink Range Variable to 10%
Image Mirroring Horizontal and/or Vertical
Horizontal Filtering Full Digital
Conversion Technology Proprietary – CORIO®2
Framerate Conversion Temporal
Color Resolution 24-bit (16.8 Million Colors)
Sampling Rate 162MHz
Digital Sampling 24-bit, 4:4:4 format
De-interlacing
(PAL-NTSC)
Pixel-level Motion Adaptive,
Diagonal Interpolation
Firmware Memory Flash, Upgradeable via RS-232
Video Encoder 8-bit Digital
Video Adjustments R-G-B Levels
Operational Modes
(C2-2155A)
Key Chromakey or Lumakey
Mix Mix PC to/from Video
PIP Variable Window Size & Position
Genlock Adjustments
Subcarrier Lock Range +/- 200Hz for NTSC Operation
(+/- 250Hz for PAL Operation)
Subcarrier Phase
+/- 180°
SDI Jitter
SMPTE259M-C
(SD-SDI)
(270Mbps:525/625Line)
Jitter 0.070 +/-0.01 UI
SMPTE292M
(HD-SDI)
(1.485/1.4835Gbps:
720p, 1035i, 1080i, 1080p)
Jitter 0.176 +/- 0.02 UI
Input Vertical Rates - SMPTE259M-C (SD-SDI)
525i (720x488) 59.94Hz
625i (720x576) 50 Hz
Input Vertical Rates - SMPTE292M (HD-SDI)
720p (1280x720)
23.98, 24, 25, 29.97, 30, 50,
59.94, 60Hz
1035i (1920x1035) 29.97, 30Hz
1080i (1920x1080) 25, 29.97, 30Hz
1080p (1920x1080) 23.98, 24, 25, 29.97, 30Hz
Control Methods
Local via Front Panel Buttons & OSD
RS-232 Interface via D9 Female Connector
IP Interface RJ45 Connector
Infrared Remote via IRC-5 Remote Unit
Input Expansion Control via D-15 Options Connector
Warranty
Limited Warranty 2 Years Parts and Labor
Regulatory Compliance
Main Units FCC, CE, RoHS
Power Supplies UL, CUL, CE, PSE, GS, RoHS
Mechanical
Size (H-W-D) 41.5x218x150mm(1.63”x8.6”x5.9”)
Weight (Net) 1.28kg (2.82 lbs)
Environmental
Operating Temperature
0° to +50° C (+32° to +122° F)
Operating Humidity 10% to 85%, Non-condensing
Storage Temperature
-10° to +70° C (+14° to +158° F)
Storage Humidity 10% to 85%, Non-condensing
Power Requirement
External Power Supply 12VDC@1.5A (Note 2)
Accessories Included
1x Operations Manual C2-2000A Series
1x Power Adapter US, UK or Euro
Product Item Numbers
C2-2105A Basic Version
C2-2155A PLUS Version with Key, Mix, PIP
Optional Accessories
RM-220 Single/Dual Rackmount Kit
S2 Series Input Expansion Switchers
Control Software Downloadable form Website
Note
(1) The C2-2155A uses the Composite Video input
provided for Key/Mix/PIP functions as a Genlock input.
The C2-2105A has a dedicated Composite Video
Genlock input.
(2) The C2 unit uses less than 1A, however, if an S2 unit is
powered via the OPTIONS connector, 1.5A is required.
