1. Handle bar
2. Wiper motor
3. Dash board
4. Hand brake control lever
5. Master cylinder assembly
6. Brake pedal
7. Driver seat
DRIVER CABIN - RH
CONTROL SWITCHES - LH
8. Turn signal lamp switch
9. Head lamp ON / PARK / OFF switch
10.Head lamp High / Low beam switch
CONTROL SWITCHES - RH
11. Wiper switch
12. Horn switch
13. Single Start Stop Switch
CONTROL SWITCHES - LH CONTROL SWITCHES - RH
