INSTRUCTIONS FOR USE
CC 100
Functions.
1 = on, 2 = temperature settings, 3 = off, 4 = lighting, 5 = move left, 6 = reduce
temperature/time and move down, 7 = move right, 8 = increase temperature/time and
move up, 9 = settings menu, 10 = information menu, 11 = display.
12 = built-in, factory-set processor, can be customised as desired.
A simplified version of these instructions are found under INFO in CC 100.
CC 100 has a built-in power reserve and you can choose between 7 different
languages.
After each power failure, the model designation of the control panel is displayed
for five seconds.
Lighting.
Lights automatically when the facility starts and switches off automatically when the
facility shuts down. You can also switch the lighting on or off manually by pressing
LIGHT.
Password.
Prevents unauthorised changing of the settings.
Main power switch.
There is a main power switch on the bottom of the relay box, SE heater and the smaller
steam generators. You need only use this switch if the facility is to be switched off for a
long time.
The thermometer should be placed at such a height that the temperature corresponds
exactly to the numbers displayed on the CC 100.
Stand-by.
Stand-by is invaluable for saunas or steambaths in hotels, bath houses and so on, where
the frequency of use varies. During low-frequency periods, the facility is set on energy-
saving "stand-by", which can quickly accelerate to the desired bathing temperature
when you press ON. The stand-by function saves significant amounts of money each
year.
The examples below show how easy it is to programme a suitable bath schedule.
Stand-by examples:
Three different bath facilities are open between 8 a.m. and 8 p.m. The bathing
frequencies of the facilities varies like this:
Alt. 1) A small number of bathers come sporadically throughout the day. Programme
stand-by between 8
00
and 8
00
pm. The bathers (or bath attendant) activate the
programme by pressing the ON button on the CC panel, or by pressing on the separate,
external ON/OFF switch, if there is one.
Alt. 2) A small number of bathers come sporadically between 8
00
and 2 pm. After 2 pm,
there is a steady flow of guests until closing. Programme stand-by between 8
00
and 8
pm and programme a fixed ”ON” time between 2 pm and 8 pm. The sporadic bathers
activate the programme by pressing the ON button on the CC panel, or by pressing on
the separate, external ON/OFF switch, if there is one.
Alt. 3) A large number of bathers between 8
00
and 10
00
, 1 pm and 2 pm and 6 pm and 8
pm. The rest of the day, only sporadic bathers come. Programme stand-by between 8
00
and 8 pm, programme fixed ”ON” times for the steady bath times. The sporadic bathers
activate the programme by pressing the ON button on the CC panel, or by pressing on
the separate, external ON/OFF switch, if there is one.
SETTINGS
CC 100 all models
Note: for all settings, the Tylarium should be switched OFF.
Language.
Press MENU – Use the left and right arrow keys (
) to move to choice of language.
Start programming mode by pressing the down arrow (
).
Use the left and right arrow keys (
) to select the language. Press the up arrow (
) to
exit and press MENU to change language.
Time (clock).
Press MENU – Use the left and right arrow keys (
) to move to clock settings. Start
programming mode by pressing the down arrow (
).
Use the up and down arrow keys (
) to set the day. Move to the hour setting by
pressing the right arrow (
). Set the hour using the up and down arrows
(
), and shift to minutes with the right arrow (
). Change the minutes using the up
and down arrows (
).
Press MENU to exit. (
).
SETTINGS
Note: CC 100-3B/3S/12B/12S only
Note: for all settings, the Tylarium should be switched OFF. To be changed
more than once: However, temperature and humidity settings can be changed
when the Tylarium is ON.
MANUAL ON/OFF.
Note: CC 100-3B/3S/12B/12S only
Setting the bathing temperature.
Press TEMP – the previous temperature is displayed. Use the up and down arrows (
) to change the temperature.
Manual on/off.
Press ON to switch the facility on. Press OFF to switch it off. If you forget to switch it off
manually, the generator automatically switches off after 3 or 12 hours – depending on
the type of control panel.
AUTOMATIC ON/OFF.
Note: CC 100-3B/3S/12B/12S only
Setting on/off and temperature.
Press MENU – Use the left and right arrow keys (
) to move to timer settings. Use
the down arrow (
) to start programming mode.
Use the up and down arrows (
) to set the start to set the start hour, then shift to
minutes with the right arrow (
). Change the minutes using the up and down arrows
(
).
Use the right arrow (
) to move to the end hour setting and then the up and down
arrows (
) to set the end hour. Shift to minutes with the right arrow (
) to set the
end time, Change the minutes using the up and down arrows
(
). Use the right arrow (
) to shift to temperature. Change the temperature using
the up and down arrows (
). Shift to on/off with the right arrow (
). Change the
on/off mode using the up and down arrows (
).
Now the setting is programmed and a red LED blinks until the sauna or steam bath
starts at the time set. After this, it glows steadily (a text on the display tells when this
happens). The sauna switches off automatically 3 or 12 hours after the pre-set time –
depending on the type of control panel.
To be changed more than once: You can switch off your sauna or steam bath manually
at any time by pressing OFF. To restart with the same settings, press MENU – Use the
right and left arrows (
) to go to timer settings. Start programming mode by
pressing the down arrow (
), shift to on/off with the right arrow (
). Change the on/off
mode using the up and down arrows (
).
STAND-BY programming.
Note: CC 100-3B/3S/12B/12S only
Press MENU – Use the right and left arrows (
) to go to stand-by setting. Start
programming mode by pressing the down arrow (
).
Use the up and down arrows (
) to set the start hour, then shift to minutes with the
right arrow (
). Change the minutes using the up and down arrows
(
).
To be changed more than once: Use the right arrow (
) to move to end hour setting
and then the up and down arrows (
) to set the end hour. Shift to minutes with the
right arrow (
). Change the minutes using the up and down arrows (
). Use the
right arrow (
) to shift to temperature. Change the temperature using the up and down
arrows (
). Shift to on/off with the right arrow (
). Change the on/off mode using the
up and down arrows (
).
Now the stand-by is programmed and a red LED blinks until the sauna or steam bath
starts at the time set. After this, it glows steadily (a text on the display shows that the
panel is in a stand-by position and when it will switch on).
As soon as you press ON, the temperature increases to the pre-set bathing
temperature. After 1 hour, the facility automatically resumes stand-by temperature.
Each time you press ON, 1 hour’s bathing time begins.
Note: if both the timer time and stand-by time are set to be on at the same time, the
timer function takes over.
To be changed more than once: You can switch off your sauna or steam bath manually
at any time by pressing OFF. To restart with the same settings, press MENU – Use the
right and left arrows (
) to go to stand-by. Start programming mode by pressing the
down arrow (
), shift to on/off with the right arrow (
). Change the on/off mode using
the up and down arrows (
).
Password
Note: CC 100-3B/3S/12B/12S only
Setting the password.
Press MENU – Use the right and left arrows (
) to go to password setting. Start
programming mode by pressing the down arrow (
). Enter the code using all the arrow
keys (
).(After power failure, the code is reset to 1995). Press MENU, use the
left arrow key (
) to change the code. Set the new code using all the arrow keys (
). Press MENU. Activate on/off with the right arrow (
), press MENU. Now the
password is activated.
To return to unlocked mode, repeat the above procedure but set on/off to off.
Note: Do all other settings before setting the password.
1
