Lighting.
Lights automatically when the facility starts and switches off automatically when the
facility shuts down. You can also switch the lighting on or off manually by pressing
LIGHT.
Password.
Prevents unauthorised changing of the settings.
Main power switch.
There is a main power switch on the bottom of the relay box, SE heater and the
smaller steam generators. You need only use this switch if the facility is to be
switched off for a long time.
The thermometer should be placed at such a height that the temperature
corresponds exactly to the numbers displayed on the CC 100.
Stand-by.
Stand-by is invaluable for saunas or steambaths in hotels, bath houses and so on,
where the frequency of use varies. During low-frequency periods, the facility is set on
energy-saving "stand-by", which can quickly accelerate to the desired bathing
temperature when you press ON. The stand-by function saves significant amounts of
money each year.
The examples below show how easy it is to programme a suitable bath schedule.
Stand-by examples:
Three different bath facilities are open between 8 a.m. and 8 p.m. The bathing
frequencies of the facilities varies like this:
Alt. 1) A small number of bathers come sporadically throughout the day. Programme
stand-by between 8
00
and 8
00
pm. The bathers (or bath attendant) activate the
programme by pressing the ON button on the CC panel, or by pressing on the
separate, external ON/OFF switch, if there is one.
Alt. 2) A small number of bathers come sporadically between 8
00
and 2 pm. After 2
pm, there is a steady flow of guests until closing. Programme stand-by between 8
00
and 8 pm and programme a fixed ”ON” time between 2 pm and 8 pm. The sporadic
bathers activate the programme by pressing the ON button on the CC panel, or by
pressing on the separate, external ON/OFF switch, if there is one.
Alt. 3) A large number of bathers between 8
00
and 10
00
, 1 pm and 2 pm and 6 pm
and 8 pm. The rest of the day, only sporadic bathers come. Programme stand-by
between 8
00
and 8 pm, programme fixed ”ON” times for the steady bath times. The
sporadic bathers activate the programme by pressing the ON button on the CC
panel, or by pressing on the separate, external ON/OFF switch, if there is one.
SETTINGS
CC 100 all models
Note: for all settings, the Tylarium should be switched OFF.
Language.
Press MENU – Use the left and right arrow keys (
) to move to choice of
language. Start programming mode by pressing the down arrow (
).
Use the left and right arrow keys (
) to select the language. Press the up arrow
(
) to exit and press MENU to change language.
Time (clock).
Press MENU – Use the left and right arrow keys (
) to move to clock settings.
Start programming mode by pressing the down arrow (
).
Use the up and down arrow keys (
) to set the day. Move to the hour setting by
pressing the right arrow (
). Set the hour using the up and down arrows
(
), and shift to minutes with the right arrow (
). Change the minutes using the
up and down arrows (
).
Press MENU to exit. (
).
SETTINGS
Note: CC 100-3B/3S/12B/12S only
Note: for all settings, the Tylarium should be switched OFF. To be changed
more than once: However, temperature and humidity settings can be
changed when the Tylarium is ON.
MANUAL ON/OFF.
Note: CC 100-3B/3S/12B/12S only
Setting the bathing temperature.
Press TEMP – the previous temperature is displayed. Use the up and down arrows
(
) to change the temperature.
Manual on/off.
Press ON to switch the facility on. Press OFF to switch it off. If you forget to switch it
off manually, the generator automatically switches off after 3 or 12 hours – depending
on the type of control panel.
AUTOMATIC ON/OFF.
Note: CC 100-3B/3S/12B/12S only
Setting on/off and temperature.
Press MENU – Use the left and right arrow keys (
) to move to timer settings.
Use the down arrow (
) to start programming mode.
Use the up and down arrows (
) to set the start to set the start hour, then shift to
minutes with the right arrow (
). Change the minutes using the up and down
arrows (
).
Use the right arrow (
) to move to the end hour setting and then the up and down
arrows (
) to set the end hour. Shift to minutes with the right arrow (
) to set the
end time, Change the minutes using the up and down arrows
(
). Use the right arrow (
) to shift to temperature. Change the temperature
using the up and down arrows (
). Shift to on/off with the right arrow (
).
Change the on/off mode using the up and down arrows (
).
Now the setting is programmed and a red LED blinks until the sauna or steam bath
starts at the time set. After this, it glows steadily (a text on the display tells when this
happens). The sauna switches off automatically 3 or 12 hours after the pre-set time
– depending on the type of control panel.
To be changed more than once: You can switch off your sauna or steam bath
manually at any time by pressing OFF. To restart with the same settings, press
MENU – Use the right and left arrows (
) to go to timer settings. Start
programming mode by pressing the down arrow (
), shift to on/off with the right
arrow (
). Change the on/off mode using the up and down arrows (
).
STAND-BY programming.
Note: CC 100-3B/3S/12B/12S only
Press MENU – Use the right and left arrows (
) to go to stand-by setting. Start
programming mode by pressing the down arrow (
).
Use the up and down arrows (
) to set the start hour, then shift to minutes with
the right arrow (
). Change the minutes using the up and down arrows
(
).
To be changed more than once: Use the right arrow (
) to move to end hour setting
and then the up and down arrows (
) to set the end hour. Shift to minutes with
the right arrow (
). Change the minutes using the up and down arrows (
). Use
the right arrow (
) to shift to temperature. Change the temperature using the up and
down arrows (
). Shift to on/off with the right arrow (
). Change the on/off mode
using the up and down arrows (
).
Now the stand-by is programmed and a red LED blinks until the sauna or steam
bath starts at the time set. After this, it glows steadily (a text on the display shows
that the panel is in a stand-by position and when it will switch on).
As soon as you press ON, the temperature increases to the pre-set bathing
temperature. After 1 hour, the facility automatically resumes stand-by temperature.
Each time you press ON, 1 hour’s bathing time begins.
Note: if both the timer time and stand-by time are set to be on at the same time, the
timer function takes over.
To be changed more than once: You can switch off your sauna or steam bath
manually at any time by pressing OFF. To restart with the same settings, press
MENU – Use the right and left arrows (
) to go to stand-by. Start programming
mode by pressing the down arrow (
), shift to on/off with the right arrow (
).
Change the on/off mode using the up and down arrows (
).
Password
Note: CC 100-3B/3S/12B/12S only
Setting the password.
Press MENU – Use the right and left arrows (
) to go to password setting. Start
programming mode by pressing the down arrow (
). Enter the code using all the
arrow keys (
).(After power failure, the code is reset to 1995). Press MENU,
use the left arrow key (
) to change the code. Set the new code using all the arrow
keys (
). Press MENU. Activate on/off with the right arrow (
), press
MENU. Now the password is activated.
To return to unlocked mode, repeat the above procedure but set on/off to off.
Note: Do all other settings before setting the password.
SETTINGS
Note: CC 100-0B/0S only
Note: for all settings, the Tylarium should be switched OFF. To be changed
more than once: However, temperature and humidity settings can be
changed when the Tylarium is ON.
MANUAL ON/OFF.
Note: CC 100-0B/0S only
Setting the bathing temperature.
Press TEMP – the previous temperature is displayed. Use the up and down arrows
(
) to change the temperature.
Manual on/off.
Important! Don’t forget to set the off time. The sauna may be switched on for a
maximum of 12 hours.
Press ON to switch the facility on. Press OFF to switch it off.
