Tylo Elite User Manual

Overview
The overview screen is shown both when the heater is switched o (Figure 7) and when it is on (Figure 8).
Temperature setting
Current temperature
Current relative air humidity
(only shown if the temperature/
humidity sensor is connected on
the Combi and Tylarium models)
Current time
Remaining sauna
time
Water level in the tank (applies to
the Combi model)
Air humidity setting
Fig. 7 Fig. 8
Fig. 9
Home
Get to the Home screen (g. 9) by touching the screen in the Overview mode or by pressing the Home
button. The Activity buttons are used to start and stop the heater. A Standby button is also shown. When one
of the activity buttons is pressed, the colour changes to indicate the current status.
Activity/Status buttons
On
Standby:
O
Functions/Settings buttons
Shows that the panel is
connected to Wi (only the
Elite Wi model)
12 13
EN

Tylo Elite Specifications

General

Type	Control Panel
Material	Plastic
Power Supply	12 V DC
Operating Temperature	0 - 50°C
Humidity Range	10 - 90% RH
IP Rating	IP20
