TYM T303 - Page 59

►
►►
► FILLING DIAGRAM & CAPACITY TABLE
No. Filling point Fillings Quantity Liter (gal.)
MODEL T303/T353
1
RADIATOR Fresh clean Water(L.L.C) 7ℓ(1.85 US gal)
2
ENGINE API : CF-4 grades
Above:25°C(77°F)… SAE30 or 15W/40
0°C to 25°C(32°F to 77°F)…
SAE20 or 10W30
Below 0°C(32°F)… SAE 10W or 10W-30
5 ℓ (1.32 US gal)
3 TRANSMISSION CASE See next page * 35ℓ(9.25 US gal)
4
FRONT AXLE Gear oil #80 or #90 (API GL-4 grade) 8.2ℓ(2.166US gal)
5
FINAL DRIVE CASE(B) Gear oil #80 or #90 (API GL-4 grade)
6
Clutch pedal shaft Grease As required
7 BALL JOINT Grease As required
8 FUEL TANK Diesel fuel 33ℓ(8.717 US gal)
