FILLING DIAGRAM & CAPACITY TABLE
No. Filling point Fillings Quantity Liter (gal.)
MODEL T290/T300/T330
1 RADIATOR Fresh clean Water(L.L.C) 7ℓ (1.85 US gal)
2 ENGINE API : CD/CE grades
Above:25°C(77°F)…SAE30 or 10W-30
0°C to 25°C(32°F to 77°F)…SAE20 or
10W30
Below 0°C(32°F)…SAE 10W or 10W-30
5.7ℓ (1.51 US gal)
3 TRANSMISSION CASE See next page * 32ℓ(8.453 US gal)
4 FRONT AXLE Gear oil #80 or #90 8.2ℓ(2.166US gal)
5 CENTER PIVOT Grease As required
6 CLUTCH PEDAL SHAFT,
BRAKE PEDAL SHAFT
Grease As required
7 BALL JOINT Grease As required
8 FUEL TANK Diesel fuel 33ℓ(8.717 US gal)
60
