2019 39 D4OPTRS
MENU
BUTTON
WINTERIZED
ICON
1. First turn off the exterior water pump switch, then depress the trigger to release any
trapped pressure.
2. Disconnect the wash-down hose, and then reconnect the water manifold hose.
HI/Lo Washdown with Hose Reel
If your sweeper is equipped with a hose reel:
1. Turn the exterior water pump control switch, located on the suction side of the sweeper,
to the off position.
2. Turn the ball valve to the Wash Position.
3. Start the auxiliary engine, and turn on the water system.
4. With the wash-down wand in hand, turn the exterior water pump control switch to the
on position
Following use of the wash-down:
1. First turn off the exterior water pump switch, then depress the trigger to release any
trapped pressure.
2. Turn the ball valve back to the sweep position and ensure the water pump switch back
to the on position.
WINTERIZATION
The TYMCO water system requires freeze protection during freezing weather. The
winterization procedure will vary depending on the type of water pump and optional
winterization equipment provided with your sweeper. Your TYMCO BlueLogic
®
control
system will assist you in successfully winterizing the water system. To begin the winterization
procedure:
1. Turn on the sweeper ignition and do NOT start the auxiliary engine.
2. Press the menu button to access the page select menu.
3. Select Service Tools then Water System Winterization.
4. Follow on screen prompts to complete the winterization process.
Once completed, the water system will be electronically tagged as winterized. The
winterized icon will be shown on the main page to indicate the water system is winterized.
The winterization tag will be removed when the presence of water is sensed in the system.
For more information on the winterization procedure, refer to your parts and service manual.
