DocNo.FM0416issueBPage2
1.INTRODUCTION

TheAdventxtprinterrecordsthetimeanddateofallcallsmade/answered/cancelledonthewardencallsystem.All
othersystemactivitysuchastelephonelinefault,mainsfail,systemreset,etc.isalsorecorded.

2.PUSHBUTTON

Thepushbuttonperformsseveralfunctions;clickoncetoturntheprinteron,pressandholdforpaperfeedwhen
changingpaperrollsordouble‐clicktoperformaself‐testandprinttheinternalsettings.

3.LEDINDICATOR

TheLEDindicatoronthefrontoftheprinterwillnormallyflashshortgreen‐longorange,thereareanumberof
othercolourcombinationswhichprovideprinterstatusinformation;

LEDPattern BatteryStatus BufferMode
ShortGreen‐LongOrange TrickleCharging Normal
LongOrangeFlashing TrickleCharging Spool
SteadyGreen RunningonBattery Normal
FastFlashingGreen RunningonBattery Spool
LongGreen‐ShortRed BatteryLow Normal
ShortGreen‐ShortRed BatteryLow Spool
FastFlashingOrange FastCharging Spool
FastFlashingRed ErrorCondition Spool
NoLED BatteryFlat‐orprinterinsleepmode

TheprinterwillenterSpoolModeifthepaperrunsout,thepapercompartmentflapisuporanerrorhas
occurred.Datawillbebufferedforprintingwhentheconditionisrectified.

4.BATTERYSTANDBY

IfthemainssupplyisdisconnectedtheLEDwillbesteadygreenforapre‐programmedtimeuntiltheprinterenters
sleepmode.Whenthemainssupplyisrestoredclickthepushbuttontoreturntostandbymodeandanymissedcalls
willbeprinted.

5.PRINT‐OUTDETAILS

Theprint‐outisdesignedtogiveasmuchinformationaspossibleaboutthestatusofthesystemwhilstusingthe
minimumofpaper.Allalarmcallprint‐outsarerestrictedtoonelineoftextinthefollowingformat:

Alarm
Prefix
Channel
ID
Call
Type
Date
(DDMM)
Time
(24HR)
Operating
Mode

Example:AL0001INTERCM22/1214:20ON

Theaboveexampletellsyouanintercomalarmfromflat1wasdetectedat14:20on22Decemberandthesystem
wasoperatinginonsitemode.Seebelowfordetailsoftheabbreviationsused;

ALARMPREFIXES

AL AlarmCallSA SystemAlarm
CA CallAnsweredSR SystemReport
CE CallEndedFN FunctionStart/FinishTime(eg.FN1000=AllCall)
CB CallBackStart/FinishTime   


