U.S. General 91039 - Jack Parts List

Page 8SKU 91039
Jack Parts List
Item Description Qty
1 Frame 2
2 Washer 2
3 Cover Nut 2
4 Handle Bar 1
5 Washer 2
6 Washer, Inner Tighten 20
7 Screw 20
8 Screw Bushing 2
9 Rear Wheel Set 2
10 Rear Wheel Saddle 2
11 Linkage Washer 2
12 Case 2
13 Axis, Arm Raise 1
14 Axis, Link Rod 2
15 Washer, Link Rod 2
16 C-ring 2
17 Screw, Inner Set Angular 2
18 Link Rod 2
19 Caster, Front Wheel 1
20 Axis 1
21 Lift Arm 1
22 Spring 1
23 Eye Bolt 1
24 Eye Bolt 1
25 C-ring 4
26 Axis, Pull Rod 2
27 Power Unit Assy. 1
28 Axis, Handle Base 2
29 Handle Base 1
30 Joint Connector 1
31 Handle, Upper 1
32 Bolt, Hex 1
33 Handle, Lower 1
34 Pull Rod 2
35 Snap Rings, Round Wire 2
36 Saddle Base Axis, Short 1
37 Saddle Base Axis, Long 1
38 Saddle Base 1
39 Nylon Washer 1
40 Saddle 1
41 Holder Axis 1
42 Rubber Saddle Pad 1
NOTE: Some parts are listed and shown for
illustration purposes only and are not available
individually as replacement parts.
