Pool Robotclean 3 Operating Manual and Parts List
Dear customer,
Thank you for choosing our product for cleaning your pool. We hope you enjoy using your new pool cleaner in the coming years to maintain your swimming pool. Before using your
RobotClean 3 for the rst time, take some time and read the operating instructions carefully.
Scope of delivery
1 Pool Robotclean 3
1 AC 100-230 V 50/60 Hz transformer
1 operating manual
2 foam blocks
DO NOT ENTER THE POOL WHEN THE CLEANER IS IN USE
Technical data
Parts List
1 Handle 14 Lower cover for the drive unit
2 Connection part for handle 15 Upper cover unit
3 Holder for upper cover 16 Rubber plug
4 Upper cover 17 Drive motor
5 Filter insert 18 Drive motor nut
6 PVC lamellar brush 19 Cable cover
7 Main drive roller 20 Pump motor
8 Drive belt T 10 21 Pump motor nut
9 Upper part of side cover 22 Impeller pump
10 Lower part of side cover 23 Impeller protective cover
11 Drive roller 24 Sliding support for handle
12 Drive belt 162XL 25 Pool cleaner housing
13 Circuit board (PCB) for pool cleaner
IMPORTANT SAFETY ADVICE
- Observe all warnings and instructions indicated on the transformer and pool cleaner. Failure to observe the warnings and instructions can lead to serious injuries
or material damage.
- This appliance is suitable for cleaning water at temperatures between min. 10° C and max. 35°C.
POWER BOX (Transformator)
Input voltage AC 100-230 V 50/60 Hz 1.2 A
Output voltage DC 28 V - 5.5 A
Mains cable 1.7 m
Level of protection I
Protection class IPX5
POOL ROBOT CLEANER 3
Input voltage DC 28 V - 2 A
Floating DC cable 15 m
Immersion depth 2 m
Brush PVC lamellar brushes, black
Level of protection III
Protection class IPX8
Nominal water temperature 10°C - 35°C
Type of cleaning Floor, walls, waterline
Cleaning surface max. 120 m2
Safety system (over-voltage protection) Yes
Cleaning cycle 1/2/3 hours
Filtration grade 100 Micron
Suction power 16 m3/h
Anti-winding system No
