Uberhaus 72255106 - Page 23

Page 23
Step 17
K2
K2
J
J1
J2
K1
K1
K2
J
Q
w
V
J2
Q2
w
V
×2
J1
w
V
Q1
17.1. Attach the End cap（Q) onto the Roof Corner Bar (J) with screw (V) and screw (W). As shown in
figure.
17.2. Attach the End cap（Q1) onto the Roof Corner Bar (J1) with screw (V) and screw (W). As shown
in figure.
17.3. Attach the End cap（Q2) onto the Roof Corner Bar (J2) with screw (V) and screw (W). As shown
in figure.
