M
Side Cap
1
M1
Side Cap
1
R Hook 76
S
Screen
4
S1
Curtain
4
NOTE:
The material is not to scale
N
Base Plate
2 Q2
End Cap
2
N1
Anchor Bracket
4 U
Screw M6*20
4
N2
Base Plate
2 V
Screw M6*16
95
O
Connector
2 W
Screw
4
P
Connector
6 X
Screw M6*15
32
P1
Connector
6 Z
Allen Key
3
Q
End Cap
1 Z1
Stake
14
Q1
End Cap
1
HARDWARE KIT INCLUDED
