UFH Komfort Touch+ - ELECTRICIAN; ENGINEER INSTRUCTIONS; Advanced Settings

To access advanced settings, in power o
ff
state
,
press and hold
and tap .
Press to move through the symbol settings. To adjust settings
use 

 , tap to confirm and to move to next symbol setting.
Touch+ Programmable Thermostat
 Power Supply: AC220~240V, 50/60HZ
 Load Current: 3A(Water Heating)
 Accuracy: ±0.5°C
 Room Temperature Range: 5°C - 60°C
 Remote Limit Temperature Range: 5-99°C
 Consumption: <0.3W
 Temperature Sensor: NTC
 Size: 86*86*17mm (H*W*D)
Technical Data
Advanced Settings
No. Symbol Item Parameter Setting Function Factory Default Setting
1
5E n
Sensor Reading O
ption
0:
Room Sensor
1: Remote Sensor
2: Room & Remote Sensor
0:
Room Sensor
2
05
U
Remote Temperature S
etting
5
-
99°C
42°C
3
dIF
Remote Temperature Difference Limit
-
Difference between Target Temperature and Calling For Heat
1
-
9 °C
2 °C
4
5UH
Temperature High Limit S
etting
5
-
99°C
35°C
5
5
UL
Temperature Low Limit S
etting
5
-
99°C
5°C
6
AdJ
Temperature C
alibration
Measure temp
-
Calibrate if necessary
0.1
7
F r E
Frost Protection
00: Off
01: On
00
: Off
8
Po
n
Memory
00: Off
01: On
00:
Off
9 FAC Factory Default 00: To Restore Factory Settings
08: Default Display Number (no meaning)
08: Default Display Number
Notes
ELECTRICIAN / ENGINEER INSTRUCTIONS

Temperature can be temporally adjusted using



or



. The hand will flash to show the temporary
temperature adjustment but will disappear and return back to auto when your next scheduled
temperature setting starts.
 Setting temperature to 00.0°C will shut down the scheduled setting
 The thermostat offers a choice of room sensor, remote sensor or alternatively both together
 When set to room sensor the display shows ROOM TEMP when set to remote sensor temperature the
display shows OUT TEMP
 When using dual sensors, to check floor temperature setting – in power on state, press and hold
then tap once
 Display will show Er if the remote sensor has been set but it is not actually connected or if it is
damaged
POWER WIRING
DIAGRAM
To open
,
push a flat screwdriver
in to both slots in the bottom of
the thermostat
Push the back from the front
as shown, remove connecting
plug
Connect up wiring as
indicated putting actuator
live on terminal 2
Screw thermostat back
plate to 35mm wall box
with screws provided
Re connect plug and
snap thermostat on
to lugs
INSTALLATION
INSTALLATION
DIMENSIONS
