1. Take out the blade knob from the shaft turning it clockwise, then take out the
rear guard knob turning it anti-clockwise. Insert the rear guard into the motor
matching 2 rods on the front side of the motor (the handle will direct upwards)
to 2 holes of the rear guard. Fasten the rear guard tightly by turning the rear
guard knob clockwise.
2. Insert the blade to the shaft and ensure the pin enters the blade slot. Tighten
the blade using the blade knob turning anti-clockwise in the direction " TIGHT"
arrow on it.
3. Fix the front guard with the logo in the upright position on the rear guard. Make
sure they are connected from the upper side and attach them tightly by closing
the clips on the front guard.
4. Attach the plastic tube to the front mist plate opening by covering it.
5. Install the pothook on the wall according to above chart, and then hang up the
mist wall fan.
Warning: Never install your fan with more than a 15 degree tilt. Otherwise your fan
will not operate properly.
