CADDY 10 UL
SPARE PARTS LIST
1 21980-00000 Cover
2 21703-00000 Pinch tube
3 22800-18730 10 lt bowl
4 21705-00000 Faucet spring
5 21704-00000 Rubber spring retainer
6 21701-00001 Push handle
7 21983-00000 Pump cover fixing clip
8 33800-05700 Evaporator assembly
9 21125-00000 Switch
10 22800-05100 Switch cap
11 22800-19300 Thermostat knob
12 33800-00803 Magnet
13 22800-04800 Motor bracket
14 22800-18901 Fan/pump motor
