Ugolini NG 6/1 User Manual

16
cylinder. Then remove the hexagonal joint (see figure 5).
figure 5
4 Remove the gasket from its housing (see figure 6).
figure 6
5 Disassemble the tap by following the order given (see figure
7).
figure 7
6 Remove the drip tray and empty it.
7 Remove the flow restrictor from the container (see figure 8).
figure 8
5. 3. 2 CLEANING
1 Pour about four litres of hot water (45-60 °C) and specific
detergent into a basin, carefully respecting the manufacturer’s
instructions. A solution that is too strong can, in fact, damage
the parts to be washed, while a solution that is too diluted may
IMPORTANT
Do not wash any part of the machine in a dishwasher.
ATTENTION
Before any cleaning operation, always unplug the
dispenser from the mains or turn off the external wall
switch.
