USING THE STABLELOCKUSING ONE TOUCH ADJUSTMENT
Tilt
Pan
Extend & Retract
Locked
Unlocked
Rotate
Both the xed and telescoping models
will tilt, pan, extend, retract and rotate
with one knob adjustment. Once
adjusted, tighten the knob to clamp
down on the boom arm for a stronger
grip, reducing slip.
To extend the telescoping u-shaped
tube, pull down on the stablelock lever,
then extend or retract the tube. Once in
the desired position, push the stablelock
lever back up to lock in place.
L
o
c
k
A
d
j
u
s
t
WARNING: The u-shaped tube does not
rotate. Extension, tilt, pan, rotating of
the mast tube is handled via one touch
adjustment knob.
