19
Configuring the Minisonic
Description of navigation
The Minisonic II Portable is equipped with a screen and a keypad for configuring it and viewing measurements directly.
Keypad
The keypad has seven keys which have dierent uses in dierent menus. However, navigation between the fields and
menus is always based on the same principles:
Switches between the measurement viewing
screens and the main configuration menu
Takes you back to the previous screen.
Changes measuring screen, moves within the
menus or changes parameter values.
Goes into the menus in reverse video and is used
to validate the parameters selected.
The menus detailed in this manual correspond to the
Normal
mode of the setup level menu.
