3.2 Installation
The pump should be installed on a level surface in a location with minimal dust, dirt
and humidity and be arranged with consideration given to ease of installation, removal,
inspection and cleaning. Particular attention should be paid to the ambient temperature
when building the pump into equipment. Use a rubber vibration isolator to separate the
pump from other equipment and to isolate the pump from the vibrations of other equipment.
Environmental conditions for storage, installation and operation
Since this pump is precisely engineered, ensure that the following conditions be
satisfied during storage, installation and operation.
① Ambient temperature, relative humidity: 7°C ～ 40°C 85% RH or less
② Height above sea level during storage and installation 1000 m or less
③ Minimum required distances from the wall 100mm or more
④ Other conditions for storage and operation
ａ．Free from corrosive and explosive gases.
ｂ．No condensation.
ｃ．Dust-free environment.
ｄ．Indoors.
ｅ．Do not place pumps on top of each other or place a pump on its side.
ｆ．Not subject to direct sunlight.
ｇ．Far from heat sources.
ｈ．When you keep it for a long period of time, put pump oil into a pump and
seal a inlet port with a cap.
ｉ．Don't keep it, where moisture is attracted.
Do not use the pump in an explosive atmosphere. Failure to do so will result in injury
or fire.
If the pump is operated whilst it is tilted, placed on its side or upside-down, the
pump will be damaged. Install the pump level with the inlet facing up as shown in
Figure1.
Caution
Warning
Note
