Example 1. Even distribution. Fertiliser dose distributed evenly throughout the width.
Example 2. Uneven distribution. Too big dose between paths, too small dose on the pass path.
LM
Right disc
3 2 1 V
4
5
6
B
Move both blades by
one hole to a lower
value.
Perform the adjustment
on the left disc, too.
1
Disc rotation
direction
Example 3. Uneven distribution. Too small dose between paths, too big dose on the pass path.
LM
Right disc
3 2 1
V
4
5
6
B
Move both blades by
one hole to a higher
value. Perform the
adjustment on the left
disc, too.
5
4
3
2
1
Disc rotation
direction
Example 4. Uneven distribution. Fertiliser dose exceeded only between the paths.
Right disc
Disc rotation
direction
Move the long blade by
one hole
to a lower value. Perform
the adjustment on the left
disc, too.
Example 5. Uneven distribution. Fertiliser dose exceeded only on the pass path.
LM
3 2 1 V
4
5
6
B
Move the short blade by
one hole
to a higher value.
6 Perform the adjustment
4 on the left disc, too.
2
Right disc
Disc rotation
direction
LM
m
1 2 3 4
2 1
V
3
4
5
6
B
Right disc
6
5
4
3
1 2 3 4
2
1
Disc
rotation
direction
m
1 2 3 4
1 2 3 4
m
1 2 3
4
1 2 3 4
m
1 2 3 4
1 2 3 4
6
3
1
m
1 2 3 4
1 2 3 4
Blades without any changes
