Uniden BCD436HP Owner's Manual

18
SETTING UP YOUR SCANNER
TURN ON THE SCANNER
Scroll
Control
Func
Menu
BCD436HP
Squelch
Volume
BCD536HP
For Model Number Procedure
BCD436HP
1. Press and hold
for about 2 seconds.
2. If the screen is too dark, tap
to turn on the backlight.
3. Press the scroll control to display the volume level. Turn the
scroll control (within 10 seconds) to adjust the volume.
4. Press the scroll control again to close the volume level (or let
it disappear after 10 seconds).
5. Press Func then press the scroll control to display the
squelch level. Turn the scroll control counter-clockwise all
the way then clockwise until the noise stops, then one notch
more.
6. Press the scroll control again to close the squelch level.
BCD536HP
1. Rotate VOL clockwise and set the volume to around 10
o’clock.
2. Rotate the SQ knob counter-clockwise all the way, and then
rotate the VOL knob to nd a comfortable volume level.
Rotate the SQ clockwise until the noise stops, then one notch
more.
The rst time you turn on your scanner it will prompt you to set the clock. See Setting the Clock.
To begin scanning right away, press the Zip button to select your country and zip/postal code (See
Data Naming to enter postcode). The scanner will load channels for your area from the database
and start scanning.

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
