Uniden BCD436HP Owner's Manual

77
Set Audio AGC
This allows you to turn AGC (Automatic Gain Control) on or off for Tone-Out operations. The
default setting is Off.
Analog - Press E/yes to toggle On or Off.
FIRE TONEOUT STANDBY/SEARCH
Press Menu. Scroll to Tone-Out for... and press E/yes.
Scroll to Tone-Out Standby and press E/yes.
(BCD536HP Only) press FUNC then SQ.
See also Set Search Key.
Scroll to monitor a Tone-Out channel (0-31).
Press Func then System to exit.
Any transmission received on the frequency will not be heard but you will still see the signal
strength bars.
To monitor a different frequency, scroll to a tone-out (channel) with a different frequency.
If you press Channel while in Standby/Search mode, the scanner temporarily exits and you will be
able to hear any transmissions on that frequency. No alerts sound, even if a tone-out matches one
you have programmed in hold mode. Press Channel again to return to Standby/Search mode.
If the scanner nds tones in Tone-Out Search mode, you will see Set Found Tone A and B? after
you press E/yes to save.
Select a Dierent Tone-Out
Turn the Scroll Control.
Listen to Tone-Out Frequency
Press Channel.
Tone-Out
channel name
Tone A and B
frequency
Tone-Out
Standby Status
Tone-Out
channel
Tone-Out Standby Mode
Tone-Out Search Mode

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
