© 2015 Unique Gas Products Ltd., 2245 Wyecroft Road, Oakville, Ontario, Canada,
L6L 5L7
www.uniqueogrid.com
TECHNICAL SPECIFICATIONS
MODEL UGP-470L
SIZE total: 16.6 cu/ft, 470 litres
OPERATION •12V/24V
DIMENSIONS
(unboxed)
H 74.5” x W 30.5” x D 28.5”
H 189 cm x W 77.5 cm x D 72.4 cm
WEIGHT 200 lbs./90.7 kg
DC POWER 12V/24V
TOTAL WATT HR. DRAW
(24 DC)
757 Wh/24hrs
(set to -14˚C freezer/+4˚C
fridge performance in a +25˚C ambient)
TOTAL AMP HR. DRAW
(24V DC)
28 Ah/24hrs (set to -14˚C freezer/+4˚C
fridge performance in a +25˚C ambient)
POWER CONSUMPTION 92 W on 12V & 78 W on 24V
AV. RUN CURRENT 6.8A on 12V & 2.9A on 24V
FRIDGE TEMP. RANGE -2˚C to +20˚C
FREEZER TEMP. RANGE -25˚C to +20˚C
