4. Control orientation by lightly loosening the inner screw (D) and rotating the dock (E) into the

desired position (horizontal or vertical). The screw (D) can be taken off completely to release

the dock (E) and reinstall it in an offset position.

5. Secure the screw (D) to lock the dock in a given orientation (make sure the light engages the

right mode when docked in).
