UNIT 1 U1 - Mounts; Saddle Mount Installation

1. Remove the screws (A) to fully disassemble the clamp.
2. Position the top half of the clamp (B) over the tube structure underneath your saddle.
3. Position the bottom clamp (C) under the tubes.
Saddle Mount
To install a Saddle Mount:
EN
A
B
C
4. Reinstall the screws (A) clamping the saddle structure.
A
18
