8. Specs
U1 Smart Light
EN
Battery Capacity : 600mA
Charging current for battery : 800mA
Battery Life:
Solid @ 100% : 180 min / 210 min
Beacon @ 100% : 900 min / 1050 min
Beacon @ 50% : 1800 mins / 2100 min
Lumens: 200 Front / 120 Rear
Working Temperature : 0 to +40°C.
U1 Charging Case
Input : DC 5V 1.0A. USB type C
Battery Capacity : 2500mAh.
Charging current for battery : 800mA
Working Temperature : 0 to +40°C
Maximum current per Smartlight docked:
475mA (By pogo pin).
Protection for over temperature and short
circuit on pogo pin.
25
