10
Please contact Universal
®
Gym Equipment/FFA Corp. for missing or defective parts at one of the following: Phone 1-800-
472-9856 or Fax 1-662-495-5038 or E-mail at customerservice@universalgymequipment.com. Mailing
address: Universal
®
Gym Equipment/FFA Corp. - 100 Tubb Ave. West Point, MS 39773.
Website www.universalgymequipment.com
FIGURE 2
Step 15.
Step 16.
Push 1/2” CAP (67) into ends of PEC DEC ARM (14 LEFT & 15 RIGHT).
Slide SPACER (57) onto PEC DEC ARM (14 LEFT & 15 RIGHT) and insert through both BEARING HOUSINGS (33) on
each side. Using an allen wrench, tighten SET SCREWS in all four BEARING HOUSINGS.
FIGURE 2
67
14
15
57
33
1
67
SET
SCREWS
To Next Page
