14
Please contact Universal
®
Gym Equipment/FFA Corp. for missing or defective parts at one of the following: Phone 1-800-
472-9856 or Fax 1-662-495-5038 or E-mail at customerservice@universalgymequipment.com. Mailing
address: Universal
®
Gym Equipment/FFA Corp. - 100 Tubb Ave. West Point, MS 39773.
Website www.universalgymequipment.com
FIGURE 5
Step 36.
Step 37.
Step 38.
Step 39.
Step 40.
Step 41.
Step 42.
Thread POP PIN (74) into PRESS ARM (8).
Push 2” ROUND END PLUGS (66) into ends of PRESS ARM (8).
Insert ROLLER HANDLE BARS (16) into PRESS ARM (8) and fasten with 1/2” NYLON NUT (101), 1/2” WASHER (96)
and 1/2” CAP FOR NUT (67).
Attach one BEARING HOUSING (33) to TOP FRAME (3) with 1/2” x 1-3/4” HEX HEAD BOLTS (82), 1/2” WASHERS
(96) and 1/2” NYLON NUTS (101). See DETAIL.
With PINS to rear insert axle of PRESS SUPPORT (7) into mounted BEARING HOUSING (33). Slide other BEARING
HOUSING onto axle and attach to TOP FRAME (3) with 1/2” x 1-3/4” HEX HEAD BOLTS (82), 1/2” WASHERS (96)
and 1/2” NYLON NUTS (101). Using an allen wrench, tighten SET SCREWS in both BEARING HOUSINGS.
Attach PRESS ARM (8) to PRESS SUPPORT (7) with 1” PRESS ARM AXLE (9) and SPACERS (57).
Pull out on POP PIN (74), swing PRESS ARM (8) to desired position and release POP PIN to lock in place.
IMPORTANT: The BEARING HOUSINGS (33) have SET SCREWS on one side. The BEARING
HOUSINGS must be mounted with the SET SCREWS to the outside as shown in DETAIL.
To Next Page
