Please contact Universal
®
Gym Equipment/FFA Corp. for missing or defective parts at one of the following: Phone 1-800-
472-9856 or Fax 1-662-495-5038 or E-mail at customerservice@universalgymequipment.com. Mailing
address: Universal
®
Gym Equipment/FFA Corp. - 100 Tubb Ave. West Point, MS 39773.
Website www.universalgymequipment.com
IMPORTANT
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING
FIGURE 1
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.
Step 7.
Step 8.
Step 9.
Step 10.
Step 11.
Step 12.
Step 13.
Step 14.
Push 50mm x 75mm END PLUGS (63) into ends of TOP FRAME (3), REAR UPRIGHT (4), WEIGHT BASE (6) and
REAR STABILIZER (10).
Attach REAR UPRIGHT (4) and WEIGHT BASE (6) to REAR STABILIZER (10) with 1/2” x 3-1/2” HEX HEAD BOLTS
(80), 1/2” WASHERS (96) and 1/2” NYLON NUTS (101).
Attach BASE FRAME (1) to WEIGHT BASE (6) with 1/2” WASHERS (96) and 1/2” NYLON NUTS (101).
Push two PLASTIC GUIDE ROD HOLDERS (69) into outer holes in WEIGHT BASE (6) and WEIGHT TOP FRAME (5).
Slide a RUBBER DOUGHNUT (58) about 3” onto one end of each GUIDE ROD (34) and insert into WEIGHT BASE (6).
Slide the WEIGHTS (37), one at a time, down the GUIDE RODS (34).
Insert the SELECTOR ROD (28) through the center hole of the TOP WEIGHT (38) and fasten through top hole of
SELECTOR ROD with TOP PLATE BOLT (76).
Slide TOP WEIGHT (38) down GUIDE RODS (34) and insert SELECTOR PIN (39) through desired WEIGHT (37) and
SELECTOR ROD (28).
Slide WEIGHT TOP FRAME (5) down onto GUIDE RODS (34) and attach to REAR UPRIGHT (4) with 1/2” x 3-3/4” HEX
HEAD BOLTS (80), 1/2” WASHERS (96) and 1/2” NYLON NUTS (101).
Attach FRONT UPRIGHT (2) to BASE FRAME (1) at two locations. Fasten at upper location with 1/2” x 4-1/4” HEX
HEAD BOLTS (79), 1/2” WASHERS (96) and 1/2” NYLON NUTS (101). Fasten at lower location with 3/8” x 3” HEX
HEAD BOLTS (85), 3/8” WASHERS (97) and 3/8” NYLON NUTS (102).
Push PEC DEC STOPPERS (52) onto stop pins of BASE FRAME (1).
IMPORTANT: The BEARING HOUSINGS (33) have SET SCREWS on one side. The BEARING
HOUSINGS must be mounted with the SET SCREWS on top as shown in DETAIL.
Attach two BEARING HOUSINGS (33) on each side of BASE FRAME (1) with 1/2” x 1-3/4” HEX HEAD BOLTS (82),
1/2” WASHERS (96) and 1/2” NYLON NUTS (101). See DETAIL.
Attach TOP FRAME (3) to WEIGHT TOP FRAME (5) with 1/2” WASHERS (96) and 1/2” NYLON NUTS (101).
Attach TOP FRAME (3) to FRONT SUPPORT (2) with 1/2” x 4-1/4” HEX HEAD BOLTS (79), 1/2” WASHERS (96) and
1/2” NYLON NUTS (101).
IMPORTANT: Loading the WEIGHT PLATES (37) will require two people. One to hold the GUIDE RODS (34)
steady while the other person slides the WEIGHT PLATES down the GUIDE RODS.
