4. Unscrew and disassemble SWITCH CABLE (#6).
5. Disassemble K/B SPRING (#7)
6. Disassemble LATCH and SPRING (#8) from the TOP HOUSING (#9).
LCD PANEL DISASSEMBLY (14” CHIMEI)
1. Unfasten SCREWS*4 (#1, #2) of the FRONT CABINET (#3).
2. Disassemble FRONT CABINET.
6
8
7 7
9
2
3
To Next Page
