Uponor Fluvia T Push-12 CH-G - Page 34

2. open 1.5 x
m [kg/h]
D
p [mbar]
10
20
30
40
50
60
80
100
200
300
3020 50 100 200 300 50010 1000
1 2
4
2.5
0.5
1.5
SI0000271
SW 10
SW 10
1. max close
Turns 0.5 1.0 1.5 2.0 2.5 4.0 Open
kv 0.14 0.27 0.38 0.46 0.54 0.65 0.66
max: 1-pipe
system
SI0000272
SW 4
max:
2-pipe system
SW 4
% flow 0 15 20 25 30 35
Turns Closed 1 1.5 2.0 3.0 Open
kv 1.25 1.45 1.5 1.55 1.65 1.8
230 V 50 Hz
N
L
N
L
SI0000273
34
|
Uponor Fluvia T pumpgroup Push-12 CH-G
|
Installation and operation manual
