2.5
2.6
2.7
Take out the quick-release device, remove
the nut and spring on one side, insert the
skewer (with the other spring on) into the
center hole of the axle, and put back the
spring and nut as illustrated.
Tighten the nut so that the lever meets
resistance at 90° from the fork, then push
it over to lock. Don’t over-tighten the nut.
Check that the lever ends up in front of
the fork and slightly ahead, so that it can
be pulled back with ease to remove the
wheel later on.
STEP 1
STEP 2
